GARDiS Proximity, MIFARE PLUS and DESfire Mullion Readers with Keypad
5002-0641
A stylish and full-featured range of mullion readers from TDSi featuring a combination of MIFARE and proximity technologies. TDSi is pleased to offer high-quality mullion readers in robust polycarbonate housings with an excellent read range.
Dimensions 45 x 130 x 17mm
Weight 250g
Operating Environment -20c to +55c, 0 to 95% RH (non-condensing)
Power Supply 7 to 14 VDC, 200mA (Max)
Operating Frequency 13.56MHz (nominal) (MIFARE), 125kHz (Proximity)
Card Technology ISO14443-A: MIFARE Classic Sector, Plus SL3 and DESfire (MIFARE) EM4100, EM4102, EM4200 and compatible (Proximity)
Sounder Integral
LED’s RGB
Read Range <25mm (ISO CARD) (MIFARE) <70mm (ISO Card) (Proximity)
Output Formats Magnetic stripe, Wiegand 26-bit** / 34-bit / 37-bit
- Compatible with 13.56MHz and 125kHz contactless smart card technology
- Fully encapsulated design
- suitable for mounting both indoor and out
- Integral LEDs
- In-built sounder
- Choice of output options
- Multiple mounting options
