MIFARE Energy Saving Switch
5002-0421
Ideally suited for hotel and student accommodation applications, these readers feature an ergonomic design featuring a blue backlit card slot. These readers have the distinct advantage that the controlled circuit will only be engaged when a card of the correct technology is inserted. The same contactless MIFARE card used for door access can be used.
The user inserts their access card into the reader to enable the integral relay this, in turn, controls lights, power circuits and other equipment. When leaving the room, the user removes the card and power is shut off after 15 seconds allowing the safe exit of the room occupants.
TDSi Part No. 5002-0421
Card Technology 13.56 MHz MIFARE
Operating Voltage 190-240 VAC, 50/60 Hz
Maximum Load 30 A, 6,600W
Standby Power 1W
Delay Time 10-20 seconds
Indications Blue LED backlight illuminate when inactive
Relay Service Life (@220 V, Full load) >10 Million operations
Operating Temperature -10~+60 °C
Operating Humidity 10~95 %RH
Overall Dimensions 86 x 86 x 35 mm
Housing Material Fire-retardant polycarbonate
Colour Grey back with gloss white cover
- Saves Energy, Saves Money
- Reduce your Carbon Footprint
- Increase Safety
- Choice of Reader Technologies
- Selective on Card Type
- High Capacity Relay
- Ergonomic Design
Energy Saving Switch Datasheet
Download
